JYP-F2408B-VT93 (TE 6450861-5) 24 signal pins + 8 power pins ,pitch 6.35mm powerblade connector power blade connector , Signal pin current 2.5A-5A,power pin's current: 40A/pin

Product Overview

A. Terminal: High performance copper alloy B. Rubber shell: High temperature resistant thermoplastic UL94V-0, Black 2. Electroplating: A. Power terminals: gold-plated in the contact area, tin plated in the soldering area, and nickel plated throughout the entire terminal; B. Signal terminals: Gold plated in the contact area, tin plated in the soldering area, and nickel plated throughout the entire terminal; C. Fixed feet: coated with matte tin on a nickel substrate; 3. Electrical performance requirements: Rated voltage: power terminal 466V AC; Signal terminal 88V AC; Rated current: 50A power terminal; 3A signal terminal; Voltage endurance: 2500V DC power terminal without breakdown for 1 minute; 1000V DC signal terminal without breakdown for 1 minute; Insulation resistance: 1000 MEG OHM MIN power terminal; 500 MEG OHM MIN signal terminal; Contact resistance: power terminal ≤ 0.7 m Ω; signal terminal ≤ 20 m Ω; Working temperature: -40 ℃ to+125 ℃ 4. Mechanical performance requirements: Plug and unplug lifespan: 250 times; 5. Packaging method: vacuum formed box packaging; 6. The product complies with the latest ROHS standards; B. Signal terminals: Gold plated in the co

Key Features

• Terminal: High performance copper alloy B.
• Rubber shell: High temperature resistant thermoplastic UL94V-0, Black 2.
• Power terminals: gold-plated in the contact area, tin plated in the soldering area, and nickel plated throughout the entire terminal;
• Signal terminals: Gold plated in the contact area, tin plated in the soldering area, and nickel plated throughout the entire terminal;
• Fixed feet: coated with matte tin on a nickel substrate;

Applications

Server and AI compute power shelves, UPS and distributed power supplies, telecom and data centre equipment, energy storage systems, EV charging piles, solar inverters, industrial power distribution and medical instrumentation.
