Domestic replacement of Amphenol powerblade connector power blade connector JYP - M2408B - RT47R-Power blade connetor blade power connector powerblade connector healthy connector mass health connector wire connector ma health connector battery terminal connector

产品概述

1. Material A. Terminal: High performance copper alloy B. Rubber shell: High temperature resistant thermoplastic UL94V-0， black 2. Electroplating: A. Power terminal: gold-plated in the contact area, tin plated in the soldering area, nickel plated throughout the entire terminal B. Signal terminals: Gold plated in the contact area, tin plated in the soldering area, and nickel plated throughout the entire terminal; C. Fixed feet: integral nickel base matte tin; 3. Electrical performance requirements: Rated voltage: power terminal 250Vac; Signal terminal 50Vac; Rated current: power terminal 40A; signal terminal 2.5A: withstand voltage: 2500VDC power terminal 1 minute no breakdown: 1000VDC signal terminal 1 minute no breakdown Insulation resistance: 2000MEGOHMMIN power terminal: 2000MEGOHMMIN signal terminal; Contact resistance: power terminal ≤ 2m2; signal terminal ≤ 20m Ω; operating temperature: -40 ℃ TO+125 ℃ 4. Mechanical performance requirements: Plug and unplug lifespan: 250 times; 5. Packaging method: vacuum formed box packaging; 6. The product complies with the latest ROHS standard 7. Order part number: JYP-F2408B-RT47R

产品特点

• Terminal: High performance copper alloy B.
• Rubber shell: High temperature resistant thermoplastic UL94V-0， black 2.
• Power terminal: gold-plated in the contact area, tin plated in the soldering area, nickel plated throughout the entire terminal B.
• Signal terminals: Gold plated in the contact area, tin plated in the soldering area, and nickel plated throughout the entire terminal;
• Fixed feet: integral nickel base matte tin;

应用领域

服务器与 AI 算力电源框、UPS 与分布式供电、通信与数据中心设备、储能系统、充电桩、光伏逆变器、工业配电与医疗仪器。
